Instructions for Behnke Hybrid series 20-0005-BS, SIP intercoms series 20-0005B-IP
GB
Commissioning and Configuration
SIP phone
Operating mode, if the device is connected to a SIP server (IP phone system) as a SIP subscriber or
if the device is supposed to communicate directly with other SIP phones (SIP direct calls)
IP intercom station
Operating mode, if the device is operated while connected with further devices as
IP intercom-station
Reset administrator password for web interface
73 * * * * #
If the administrator password for configuring the device via the web interface was forgotten, it can
be reset to the default value via this configuration step.
Subsequently, you can log on to the web interface with the given administrator password.
Network connection
74 0 #
1 #
2 #
3 #
4 #
Here you can set how the device is connected to the IP network.
Normally, the device is connected to the Ethernet port of a PoE switch via network cable.
This supplies the device with power (Power over Ethernet) and connects it to the network.
Optionally, the device can also be connected to a wireless network (WiFi).
Wired Ethernet
Connection to a LAN or an untagged VLAN
VLAN
Connection to a tagged VLAN
The VLAN tag can be set via configuration step 79.
VLAN for webcam only
Untagged connection for the device and providing a second network connection with a tagged VLAN
only to access the webcam.
The network connection for the webcam can only be configured via the web interface.
88
Wired Ethernet
VLAN
VLAN for webcam only
VLANs for device and webcam
WiFi
Default: admin
Default: 0
