2.2. Mechanical mounting Series 20/30

Insert the function modules into the front frame
Illumination 12 V=
(Line coming from the
basic electronics)
Insert the modules into the frame from the rear.
Function modules into the front frame
When inserting the modules, please make sure to maintain the anti-twist protection and also have
the modules "click" audibly into position.
54
LS
Bridges
RT
T
RT
T
RT
T
Mic
LP
RT
RT
Mic
RT
Connection of the key illumina-
tion for Behnke keys (optional
illuminated keys)
Illumina-
tion 12V=
12V-bridges to illuminate
the label positions
T
T
T
