Introduction
uneven (e.g., with silicone). Please leave the
center of the lower edge of the door intercom
station free to use as water drainage slot.
When using cover plates, the cover plate
must be sealed against the housing mounted
in-wall or the flat surface in the case of cavity
wall installations using a suitable sealing
compound or the gasket supplied.
▸
When installing in third-party pedestals or
housings respectively, suitable measures
must be taken to prevent condensation from
forming in the pedestal!
Gaskets
To protect your device from any dampness,
please make sure the included gaskets have
been put in place correctly upon installation
of your door intercom station. The gasket
must lie cleanly on the frame of the in-wall or
surface-mounted housing or, in the case of
cavity wall mounting, on the flat surface of the
mounting base! In-wall housings are available
for installation in masonry or plasterboard. You
will find the most important mounting informa-
tion inside the in-wall housings. For mounting
in plasterboard, please order the respective
mounting set (order no.: 20-5216).
In the case of cavity wall mounting, ensure
that the surface is flat and that the base is
load-bearing so that the door intercom station
can be fastened.
Cleaning and maintenance
They have installed high-quality Behnke
products with front panels made of different
materials. All materials should be cleaned with
a suitable cleaning agent in regular, sufficiently
short intervals, depending on the material.
58
This prevents early ageing and patina formation
on the surface. You can find the correspond-
ing care instructions for surfaces delivered by
Behnke on our homepage:
www.behnke-online.de/downloads/pflegehin-
weise
Original Behnke components
Please only use Behnke components for
accessories or spare parts – this also applies
to PoE injectors! This is the only way to ensure
trouble-free operation. Only install or assemble
the electronics in the supplied housings. If a
third-party housing or a housing other than the
one provided for mounting the circuit board
is used, we cannot guarantee functioning and
approval of your Behnke door intercom station.
Configuration
The SIP stations are configured during operation
via web frontend (for system requirements, see
page 57). Alternatively, some settings such
as volume etc. can be configured via telephone
with DTMF dialling or the Behnke keypad. When
operated as a/b intercom station, the config-
uration is carried out via DTMF post-dialling,
via keypad (alternatively also with the Behnke
configuration WiFi) or via display (if available in
the intercom station). Information on operation,
configuration, technical data can be found in
the detailed technical manual for the Behnke
door intercom station. To do this, select the
appropriate menu item in the web frontend of
the door intercom station.
Further important information about the con-
figuration can be found in the symbols marked
with a ? .
