Instructions for Behnke Hybrid series 20-0005-BS, SIP intercoms series 20-0005B-IP
Configuration steps 10 and 11 can be used to define two codes that apply to the indoor intercom
station (phone receiving the call) or the code lock (available via keypad or display), depending on
the selected operating mode.
In all other operating modes, the switching contact behaves like a normally open contact.
So it is usually open.
In operating mode 10, configuration step 09 can be used to define how long the additional bell is
activated at the beginning of the direct call.
In the 'Fault indication' operating mode, a fault is considered to occur when the device no longer has
a valid network connection or when a registration with the SIP server has failed.
Activation time of relay 1
09 1 # 1 second
: :
90 # 90 seconds
This configuration step is used to set the activation time for operation as a door opener relay
(operating modes 1 to 6) or the activation duration of an additional bell at the beginning of a direct
call (operating mode 10).
Activations codes for relay 1
10 1. Activation code #
11 2. Activation code #
Activation codes consist of digits only and may be up to eight digits long.
In the delivery state, the second activation code is valid for the code lock function, which is activated
on devices with keypad or display. For safety reasons, the given code must be changed.
The following special symbols are allowed at the start when entering activation codes:
*1 = Activation code applies to indoor intercom station
*2 = Activation code applies to code lock
If no special symbol is entered, the activation code applies to the last setting made.
www.behnke-online.de
Commissioning and Configuration
Default: 5
Default: 0
Default: 2580
