1.5.3.2

Target device name displays

When an appliance is added, the target device names retrieved from the appliance are
stored in the software database. The operator can then rename a target device in the
Explorer. The new name is stored in the database and used in various component
screens. This new target device name is not communicated to the appliance.
You can change target device names on both the appliance and the database by using
the Modify Device Name window in the AMP. For more information see "Modifying
target device names" on page 89.
Because the software is a decentralized management system, you can change the
name assigned to a target device on the appliance at any time without updating the
software database. Each operator can customize a particular view of the list of target
devices being managed.
Because you can associate more than one name with a single target device - one on the
appliance and one in the software - the software uses the following rules to determine
which name is used:
• The Explorer only shows the target devices listed in its database, with the name
specified in the database. In other words, the Explorer does not talk to the
appliance to obtain target device information.
• The AMP displays information retrieved from the appliance, except where noted.
• The Resync Wizard (which is used to resynchronize target device lists in the AMP)
overwrites locally-defined target device names only if the target device on the
appliance has been changed from the default value. Non-default target device
names that are read from the appliance during a resynchronization override the
locally-defined names.
1.5.3.3

Sorting

In certain displays, the software component displays a list of items with columns of
information about each item. If a column header contains an arrow, you can sort the list
by that column in ascending or descending order.
To sort a display by a column header, click the arrow in a column header. The items in
the list are sorted according to that column. An upward-pointing arrow indicates the list
is sorted by that column header in ascending order. A downward-pointing arrow
indicates the list is sorted by that column header in descending order.
1.6

On-board web interface

The on-board web interface provides similar management functions as the KVM s3
Client, but does not require a software server or any installation. The on-board web
interface is launched directly from the appliance, and any servers connected to the KVM
s2-0411 and s3-1621 appliances are automatically detected. You can use the on-board
web interface to configure KVM s2-0411 and KVM s3-1621 appliances from a web
browser. Launch the Viewer from the on-board web interface to establish KVM and
virtual media sessions to target devices.
