KNOWING YOUR NEW ESPRESSO MACHINE

3
6 7
8 9
11
12
13
15
16
17
18
EN
88
1
2
4
5
10
14
19
1 BEAN HOPPER LID tightly closing the bean hopper.
2 BEAN HOPPER for up to 220g fresh, whole coffee beans.
3 HEATED WARMING PLATE for pre-heating and keeping warm cups and glasses.
4 WATER TANK LID AND HANDLE: simply pull the water tank lid up and use it as a handle for conveniently pulling out the water tank.
Fold it back for filling the water tank.
5 2.5 L REMOVABLE WATER TANK with filling level lines (MIN and MAX).
6 POWER BUTTON: flashing during the pre-heating cycle.
7 1 CUP BUTTON: press here for extracting 1 espresso.
8 2 CUPS BUTTON: press here for extracting the programmed amount for 2 espressos.
9 GRINDER BUTTON: starts the grinder for grinding the pre-programmed amount.
10 PRESSURE GAUGE — showing the pressure during extraction.
11 DESCALING INDICATOR: illuminates, when descaling is required.
12 HOT WATER/STEAM INDICATOR: flashes while the steam function is activated; illuminates continuously with the hot water function
selected.
13 GROUP HEAD — install the portafilter at the group head for extracting espresso.
14 GRINDER OUTLET WITH GRINDING CRADLE: insert the portafilter here for grinding the coffee powder directly into the filter basket.
15 STAINLESS STEEL PORTAFILTER WITH 2 SPOUTS: fix the selected filter basket here.
16 SWIVEL STEAM WAND WITH THERMALLY INSULATED HANDLE: for pressing out hot water and steam at the steam wand tip.
17 REMOVABLE DRIP TRAY WITH METAL CUP TRAY AND RED FILLING INDICATOR: during the extraction cycle, place 1 cup
or 2 cups here.
18 GRIND SIZE DIAL — adjust the grind size according to your requirements.
19 SELECTION DIAL FOR THE STEAM WAND FUNCTIONS: hot water or steam.

ACCESSORIES

Professional - Espresso - Tamper, single-walled filter insert for 1 and 2 cups, double-walled filter insert for 1 and 2 cups,
filter insert for E.S.E. pads, milk frothing can, measuring spoon with espresso tamper, cleaning tool, water filter
