Microphone Line 1 and Line 2
AF-input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0 Ohm master, pin 7+, 6- and 14 screen, balanced, floating, adjustable -40 dB
AF-output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.55 V (+6 dBm), Pin 5+, 4- and 12 screen, balanced, floating, adjustable -40 dB
Power supply output . . . . . . . . . . . . . . . . . . . . . . . . . Pin 1 and 9 +24 V, pin 8 and 15 0 V, 6.3 A
Power supply output . . . . . . . . . . . . . . . . . . . . . . . . . Pin 11 and 13 -24 V, pin 8 and 15 0 V, 2.9 A
Data-Bus-line (CPU) . . . . . . . . . . . . . . . . . . . . . . . . . . Pin 2 = A, Pin 3 = B, Pin 10 = screen
Multipin connector
Line-input Extension. . . . . . . . . . . . . . . . . . . . . . . . . . Pin 1+ and 2 screen, unbalanced, floating, 1.55 V (+6 dBm)
Line-input AF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Pin 3+, 4- and 5 screen, balanced, floating, 20 mV adjustable -40 dB
Line-input AUX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Pin 6+, 7- and 8 screen, balanced, floating, 250 mV adjustable -40 dB
Line-output Return. . . . . . . . . . . . . . . . . . . . . . . . . . . Pin 9+ and 10 screen, unbalanced, floating, 1.55 V (+6 dBm)
Line-input Send . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Pin 11+, and 12 screen, unbalanced, floating, 1.55 V (+6 dBm)
Line-output Record. . . . . . . . . . . . . . . . . . . . . . . . . . . Pin 13+ and 14 screen, unbalanced, floating, 250 mV (-10 dBm)
MCS 1011 Delegate Microphone Unit
Power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ±24 V via microphone line
Power consumption . . . . . . . . . . . . . . . . . . . . . . . . . . max. 33 - 70 mA
AF-frequency response . . . . . . . . . . . . . . . . . . . . . . . . 50 Hz to 19,000 Hz
T.H.D. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ≤ 0.5%
Signal-to-noise ratio with microphone . . . . . . . . . . . ≥ 60 dB related to 1 Pa
AF-Output (+6 dBm) . . . . . . . . . . . . . . . . . . . . . . . . . . balanced, microphone line
AF-Output (-10 dBm) . . . . . . . . . . . . . . . . . . . . . . . . . unbalanced, mini-jack (3.5 mm)
Limiter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . compensates variations in speaking distance
1 button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Microphone button
1 DIP-switch (No. 6) . . . . . . . . . . . . . . . . . . . . . . . . . . Special function. In the ON-position the priority-function is
5 DIP-switches (No. 1 to 5) . . . . . . . . . . . . . . . . . . . . . Address of the microphone units (Binary code)
Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 x 14-pin socket for loop connection
Dimensions (without microphone) . . . . . . . . . . . . . . . Length: 190 mm
Weight (without microphone) . . . . . . . . . . . . . . . . . . 775 g
Colour . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Nextel
MCS 1013 Chairman Microphone Unit
Power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ±24 V via microphone line
Power consumption . . . . . . . . . . . . . . . . . . . . . . . . . . max. 33 - 70 mA
AF-frequency response . . . . . . . . . . . . . . . . . . . . . . . . 50 Hz to 19,000 Hz
T.H.D. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ≤ 0.5%
Signal-to-noise ratio with microphone . . . . . . . . . . . ≥ 60 dB related to 1 Pa
AF-Output (+6 dBm) . . . . . . . . . . . . . . . . . . . . . . . . . . balanced, microphone line
AF-Output (-10 dBm) . . . . . . . . . . . . . . . . . . . . . . . . . unbalanced, mini-jack (3.5 mm)
Limiter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . compensates variations in speaking distance
3 buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1. Priority button
5 DIP-switches (No. 1 to 5) . . . . . . . . . . . . . . . . . . . . . Address of the microphone units (Binary code)
Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 x 14-pin socket for loop connection
Dimensions (without microphone) . . . . . . . . . . . . . . . Length: 190 mm
Weight (without microphone) . . . . . . . . . . . . . . . . . . 775 g
Colour . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Nextel
acc. to RS 485 standard
transferred to the microphone button. In the configuration this
microphone unit has to be configured as chairman using the
MCS-Editor software.
1 x mini-jack (3.5 mm), documentation-output
Width: 102 mm
Height: 52 mm
®
, stone grey (B 2)
2. Microphone button
3. Clear button
1 x mini-jack (3.5 mm), documentation-output
Width: 102 mm
Height: 52 mm
®
, stone grey (B 2)
63
