Short Description
1.1 MCS 100
The MCS 100 is a self-contained discussion control unit with integrated power supply and processor control for 64 microphone
units. It is a stand alone unit with multi-function buttons and LC-Display in a desktop housing. With this system the 1000-series micro-
phone units can be operated. The discussion control unit is delivered with a manufacturer specific configuration. The user, however, can
carry out a configuration of the system by himself. The configuration is controlled by using the multi-function buttons and the LC-
Display. For an extensive configuration, a PC can be connected to the service port and the supplied MCS-Editor software must be used.
All functions of the discussion control unit can be configured using this software. The system operates in a bus mode.
Safety Information
•
Never expose the unit to water or excessive humidity. Do not install near swimming pools, spas, in a wet basement or in other
excessively humid environments.
•
Never pour any liquids into the unit.
•
Do not install or use this unit near sources of high heat, such as radiators, heat registers, flood lamps, spotlights, stoves, or other
appliances.
•
Always route cables running to the unit where they will not be pinched or cut by heavy or sharp objects.
•
Always turn off the power to the amplifier when making input or output connections.
•
Verify that the voltage rating of the unit matches that of the AC mains outlet you are to use. If you connect the unit to the wrong
voltage, you may seriously damage it.
•
Do not put wires or small objects through any of the ventilation grilles. Electric shock may result.
•
This unit needs a sufficient ventilation. Therefore, never cover the ventilation grilles. If you install the unit into a rack leave a
minimum distance of 1 U above and below the unit.
•
Never place burning objects onto the unit.
1.2 Microphone Units
For the MCS 100 discussion control unit there are various chairman and delegate microphone units available.
All microphone units (delegates and chairman) are equipped as follows.
• A 14-pin socket for the connecting cable.
• A mini Mono jack for the connection of recorders, dictating machines etc.
• A cardioid gooseneck microphone.
• A Dual-LED that illuminates green when the microphone unit is switched on. When the system is operating in the Request-to-Talk
mode, the LED is illuminated red to indicate the registration as a Request-to-Talk. When the microphone is ready, the colour
changes to green.
• An illuminated ring to indicate the Ready-to-Talk condition of the microphone unit.
• On the bottom of the microphone units there are DIP-switches for programming the microphone units.
Microphone Units with Loudspeakers
• Same as above with built-in wide-range loudspeaker.
• On the bottom of the unit there is an individual output volume control for the loudspeaker adjustable from 0 dB to -20 dB this is
in addition to the system level which is controlled via the MCS 100 (installation circumstances may demand lower loudspeaker levels
to avoid feedback).
