MCS <-> PC or
Command
control panel
'PXXX', CR
'RXXX_', CR
'PXXXM', CR
'PXXXP', CR
'RXXXAN', CR
'P065', CR
'P066', CR
'P067', CR
'P068', CR
'P068', CR
'R068', CR
'P069', CR
'P069', CR
'P070', CR
'R070', CR
'P071', CR
'R071', CR
R072', CR
104
Data Flow
<-
Post status changing, 3 different ways:
a) post not speaking will lead to post speaking
b) post on Request-to-talk list will lead to post speaking
(list must be updated too)
c) post speaking will lead to post not speaking
XXX = Post number (000 - 064)
-> Microphone status not active, post icon on PC is off, no text.
XXX = Post number (000 - 064)
_ = Space (0x20)
-> Microphone status active. Post icon on PC is on.
Text = M means normal delegate.
XXX = Post number (000 - 064)
M = Micro Normal Delegate
-> Microphone status active. Post icon on PC is on.
Text = P means chairman
XXX = Post number (000 - 064)
P = Micro "Präsident" (German for chairman)
-> Microphone status not active but post in request-to-talk list.
Text = A means "Anmeldung" (German for Request-to-talk).
XXX = Post number (000 - 064)
N = Position on the request-to-talk list (1 - 9)
1 means first on the list, 9 = last on the list
<- MCS 100 Reset.
MCS is set into default switch-on mode
MCS 100 sends echo 'P065', CR
<- Clear Request-to-Talk list.
Inside the MCS 100 the request-to-talk list is cleared.
MCS 100 sends echo 'P066', CR and updates request-to-talk list.
(only requests to talk)
<- Next function
Station with highest priority in request-to-talk list will be switched on (if max. NOM not
reached yet) and will be erased from this list.
MCS 100 sends echo 'P067', CR and updates request-to-talk list.
<- Clear function
All delegate mics will be cleared, chairman status stays as it is.
MCS 100 sends echo 'P068', CR and updates request-to-talk list.
-> MCS sends 'P068', CR, 'R068', CR when clear button is pushed at any of the chairman
stations.
<- Clear function
All delegate mics will be cleared. Chairman status stays as it is.
No echo will be sent.
Internal flag will be set so that only 'P069', CR will be sent when the clear buttons are
pushed on the chairman stations.
This flag enables to hook-up also not intelligent control panels. The flag is cleared when
turning off the power on the MCS 100.
-> This command will be sent from the MCS when clear button on chairman station is
pushed and command 'P069', CR was sent to the MCS 100 before.
<- Volume - (decrease)-
Output level is lowered gradually
MCS 100 sends echo 'P070', CR
<- Stop lowering output level
MCS 100 sends echo 'R070', CR
<- Volume + (increase)
Output level is increased gradually.
MCS 100 sends echo 'P071', CR
<- Stop increasing output level.
MCS 100 sends echo 'R071', CR
<- Change mode to Request-to-Talk
MCS 100 sends echo 'P072', CR
followed by a reset of MCS 100
Function
