Data Flow
MCS <-> PC or
Command
control panel
'R073', CR
<-
'R074', CR
<-
'R075', CR
<-
'P080', CR
<-
'P081', CR
<-
'P082', CR
<-
'P083', CR
<-
'P084', CR
<-
'P085', CR
<-
'P086', CR
<-
'P087', CR
<-
'P088', CR
<-
'P089', CR
<-
'P090', CR
<-
'P091', CR
->
'P092', CR
->
'P093', CR
<-
'P094', CR
<-
'R500XX', CR
->
'R501XX', CR
->
'R502XX', CR
->
'R503XX', CR
->
'R504XX', CR
->
'R505XX', CR
->
´BXXX´,CR
<-
Change mode to Manual.
MCS 100 sends echo 'P073', CR
followed by a reset of MCS 100
Change mode to Override
MCS 100 sends echo 'P074', CR
followed by a reset of MCS 100
Change mode to Automatic (voice controlled)
MCS 100 sends echo 'P075', CR
followed by a reset of MCS 100
Public voting
MCS 100 sends 'P080', CR, 'R081', CR
Secret voting
MCS 100 sends 'R080', CR, 'P081', CR
Start parliamentary voting.
MCS 100 sends 'P082', CR, 'R083', CR, 'R084', CR, 'R085', CR
Start multiple choice.
MCS 100 sends 'R082', CR, 'P083', CR, 'R084', CR, 'R085', CR
Start opinion poll.
MCS 100 sends 'R082', CR, 'R083', CR, 'P084', CR, 'R085', CR
Voting break
MCS sends ''P085', CR
Continue voting
MCS sends echo and ''P085', CR
Terminate voting
MCS sends echo and 'R082', CR, 'R083', CR, 'R084', CR, 'R085', CR
Show voting results
MCS sends echo and results as described under command 500-505
Vote results will be sent to large LC-display (via RS 485 serial port on MCS 100)
MCS sends echo
Status check
MCS sends 'OK', CR
One of the chairmen has activated the priority function.
MCS sends echo and 'P093', CR
One of the chairmen has deactivated the priority function.
MCS sends echo and 'P094', CR
Activation of Priority Status
MCS sends echo
Deactivation of Priority Status
MCS sends echo
Number of present participants will be sent
XX is a decimal value between 0-64
Number of delegates who pushed button 1
Number of delegates who pushed button 2
Number of delegates who pushed button 3
Number of delegates who pushed button 4
Number of delegates who pushed button 5
Turn on blinking mode of an individual unit XXX = 001 - 064
This mode stays until the unit's status is changing again.
Function
105
