9.
Trouble Shooting
Problem
Error message "Wrong number of
microphones" displayed
No sound when the microphone units
are switched on
Distorted sound
Green LED in the housing illuminates;
ring on the gooseneck is not illuminated
Connection to PC is not set up
(MCS-Editor to MCS 100)
10.
Versions
Discussion Control Unit
MCS 100
Discussion Control Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Order # 450.952
Microphone Units
MCS 1011
Delegate microphone unit with microphone button . . . . . . . . . . . . . . . . . . . . . . Order # 458.880
MCS 1021
Delegate microphone unit with microphone button and loudspeaker . . . . . . . . Order # 458.961
MCS 1013
Chairman microphone unit with microphone button . . . . . . . . . . . . . . . . . . . . . Order # 458.945
MCS 1023
Chairman microphone unit with microphone button and loudspeaker . . . . . . . Order # 458.988
MCS 1020
Press station without gooseneck and microphone button. . . . . . . . . . . . . . . . . . Order # 458.953
MCS 1036
Delegate microphone unit for voting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Order # 455.318
MCS 1038
Chairman microphone unit for voting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Order # 455.326
MCS 1213
System microphone unit for mounting under the table . . . . . . . . . . . . . . . . . . . Order # 453.803
MCS 1223
same as above, but with loudspeaker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Order # 455.431
MCS 1613
System unit for remote installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Order # 454.176
MCS 1623
same as above, but with connection for loudspeaker . . . . . . . . . . . . . . . . . . . . . Order # 453.811
11.
Optional Accessories
Software
MCS Controller
Operation and Configuration software for PC-control under Windows
Possible Cause
Too few or too many microphone units
as configured in the configuration
Gooseneck not properly connected in
some microphone units, thus the supply
voltage and the address of the
microphone units is missing
Cable connection interrupted
Insert switched on without an effect
device being connected
Input switched off
Gain is too low on the selected input
Input overloaded
Gooseneck is not connected properly
Defective cable
Wrong interface has been configured in
the MCS-Editor
Solution
New configuration
Use the MCS-Editor to check the
microphone units and connect the
gooseneck properly (refer to chapter
"6.8 Status Check")
Use the MCS-Editor to check the
microphone units and connect the
missing microphone unit
Connect an effect device or switch off
the insert
Use the MCS-Editor to switch on the
input in the configuration
Use the buttons of the MCS 100 to
increase the level of the concerning
input amplifier (8. Parameter)
Use the buttons of the MCS 100 to
decrease the sound of the concerning
input (10. Parameter)
Check and connect the gooseneck
properly (refer to chapter "6.8 Status
Check")
Connect a new cable
Use the MCS-Editor to configure a new
interface
®
. . . . . . . Order # 452.580
61
