9. Parameter
Output level
More
Reset
N.o.m.
-4 dB
-
+
Reset
N.o.m.
10. Parameter
Tone control
More
Reset
N.o.m.
Treble
More
Reset
N.o.m.
0 dB
-
+
Reset
N.o.m.
11. Parameter
Insert
More
Reset
N.o.m.
On
Off
Reset
N.o.m.
In this menu the overall volume of the loudspeakers in the microphone units can be adjusted. The
adjustment is done when all input levels have been matched to each other with the same volume.
The adjustment of the output level is done in 2 dB-steps.
Important:
The main output level of the AF Output (8) and Record (16) for external devices (e.g. external sound
reinforcement system) is not affected.
In this menu treble and bass of the microphone units is adjusted.
Pressing the right button (5) you can choose between the adjustment of treble and bass. Pressing
the left button (4) you enter the chosen menu item.
Treble or bass can be adjusted between +12 dB and -12 dB.
In this menu the insert can be activated, when an external device for signal processing (e.g.
equaliser) has been connected that is at the "Send" output (15) the signal is routed, externally
processed (e.g. equaliser) and returned via the "Return" input (14). The signal processing affects
only the signal of the microphones in the microphone units. The output level at the output for
external devices (e.g. external sound reinforcement system) is not affected.
The present adjustment appears in the top line.
If no device for signal processing has been connected, the insert has to be switched off i.e. the left
button (4) has to be pressed as shown in this example.
47
