Proper cleaning, maintenance and the use of clean, dry, quality fuel will prevent common operational problems. When your Pit
Boss® grill is operating poorly, or on a less frequent basis, the following troubleshooting tips may be helpful. For FAQ, please visit
www.pitboss-grills.com . You may also contact your local Pit Boss® authorized dealer or contact Customer Service for assistance.
WARNING: Always disconnect the electrical cord prior to opening the grill for any inspection, cleaning,
maintenance or service work. Ensure the grill is completely cooled to avoid injury.
PROBLEM CAUSE
No Power Lights On Temperature Control
The Control Board Dial is still off.
Not Connected To Power
Source
Fuse Blown On The
Control Board
Faulty Control Board
Fire in Burn Pot Will Auger Not Primed
Not Light
Auger Motor Is Jammed
Igniter Failure
Insufficient Air Flow
Through Burn Pot
Flashing Dots On LCD The Igniter Is On
Screen
Flashing Temperature Grill Temperature Is
On LCD Screen Below 65°C /150°F
18

TROUBLESHOOTING

SOLUTION
Turn the Temperature Control Dial to a temperature setting.
Ensure unit is plugged into a working power source. Reset breaker. Ensure GFCI is a minimum 10 Amp
service (see Electric Wire Diagram for access to electric components) Ensure all wire connections are
firmly connected and dry.
Remove hopper access panel (see Electric Wire Diagram for diagram), press in plastic tabs holding the
control board in place and carefully pull controller inside the hopper to release controller. Check the fuse
for a broken wire or if the wire has turned black. If yes, fuse needs to be manually replaced.
Control Board needs to be replaced. Contact Customer Service for a replacement part.
Before the unit is used for the first time or anytime the hopper is completely emptied out, the auger
must be primed to allow pellets to fill the auger tube. If not primed, the igniter will timeout before the
pellets reach the Burn Pot. Follow Hopper Priming Procedure .
Remove cooking components from the main barrel. Press the Power Button to turn the unit on, turn
Temperature Control Dial to SMOKE, and inspect the auger feed system. Visually confirm that the auger
is dropping pellets into the Burn Pot. If not operating properly, call Customer Service for assistance.
Remove cooking components from the main barrel. Press the Power Button to turn the unit on,
turn Temperature Control Dial to SMOKE, and inspect the igniter. Visually confirm that the igniter
is working by placing your hand above the Burn Pot and feeling for heat. Visually confirm that the
igniter is protruding approximately 13mm / 0.5 inches in the Burn Pot. If not operating properly, follow
Manual Start-up Procedure to continue use of grill; however, call Customer Service for assistance or a
replacement part.
Check Burn Pot for ash build-up or obstructions. Follow Care and Maintenance instructions for ash build-
up. Check fan. Ensure it is working properly and air intake is not blocked. Follow Care and Maintenance
instructions if dirty.
This is not an error that effects the grill. Used to show that the unit has power and is in Start-Up mode
(igniter is on). The igniter will turn off after five minutes. Once the flashing dots disappear, the grill will
begin to adjust to the desired temperature selected.
This is not an error that effects the unit; however, it is used to show that there is some risk that the fire
could go out. Check hopper for sufficient fuel or if there is an obstruction in the feed system. Remove
pellets and follow Care and Maintenance instructions. Check grill Grill Probe and follow Care and
Maintenance instructions if dirty. Check Burn Pot for ash build-up or obstructions, and follow Care and
Maintenance instructions for ash build-up. Check fan. Ensure it is working properly and air intake is not
blocked. Follow Care and Maintenance instructions if dirty. Check auger motor to confirm operation
(rotation), and ensure there is no blockage in the auger tube.
