Replacing The Top Burner Pilot Light Nozzle; Replacing Oven Burner Pilot Light Nozzle - Angelo Po 2N1FAGF Bedienungshandbuch

Undo the locking screw (E).
5)
Extract the bushing (F) and replace it with the
6)
one suitable for the type of gas in use (see
table at back of manual).
Adjust the position of the bushing (F) (see
7)
page 14).
Tighten the screw (E).
8)
Replace the panel (D) and the rack (C) on com-
9)
pletion of the operation.
To carry out this operation, proceed as follows.
Turn off the gas supply tap.
1)
Pull off the knob (A).
2)
Take out the screws (C) and take down the
3)
dashboard (B).
Svitare il raccordo (D).
4)
Remove the nozzle (E) and replace it with the
5)
one suitable for the type of gas in use (see
table at back of manual).
Retighten the union (D).
6)
Replace the control panel (B) and the knobs
7)
(A) on completion of the operation.
GB
To carry out this operation, proceed as follows.
Access the pilot light through the opening
1)
provided in the bottom of the appliance.
Unscrew the cap (B).
2)
Unscrew the nozzle (C) and replace it with
3)
the one suitable for the type of gas in use (see
table at back of manual).
Replace the cap (B).
4)
3301360_inst_GB_rev.1

REPLACING THE TOP BURNER PILOT LIGHT NOZZLE

REPLACING OVEN BURNER PILOT LIGHT NOZZLE

A
B
- 20 -
E
F
D E
C
C
C
B
10
ENGLISH
