Testing Of The Appliance - Angelo Po 2N1FAGF Bedienungshandbuch

Caution - Warning
Before doing any work, cut off the mains
electricity supply.
Undo the screws (A) and remove the control
1)
panel (B).
Modify the connections of the terminal board
2)
(C) as shown in the diagram and in the electri-
cal system diagram at the back of the manual.
Replace the control panel (B) on completion
3)
of the operation.
Remove the test voltage indicator sticker
4)
from the dataplate and apply the new one to
identify the voltage being used.
Important
On completion of the operation make sure
that there are no malfunctions.
Important
Before it is put into service, the system must
be tested to check the operating conditions
of every single component and identify any
malfunctions. In this stage, it is important to
check that all health and safety requirements
have been complied with in full.
To test the system, make the following checks:
Check that the mains voltage is the same as
1)
that of the appliance
Operate the appliance's circuit-breaker to
2)
check the electrical connection.
Turn on the gas supply tap and check that the
3)
connections are right.
Check that the mains gas is the same as that
4)
used for commissioning of the appliance, and
carry out the conversion procedure if neces-
sary (see page 11).
3301360_inst_GB_rev.1

TESTING OF THE APPLIANCE

Check that the top and oven burners are light-
5)
ing correctly and their combustion.
Check the gas pressure and fl ow-rate at
6)
minimum and maximum settings and adjust if
necessary (see page 6).
Check that the safety device is operating
7)
correctly.
Check that there are no gas leaks.
8)
Check that the nameplates specify the correct
9)
gas for the country of use.
After testing, if necessary instruct the user in all
the skills necessary for putting the appliance
into operation in conditions of safety, in accord-
ance with legal requirements.
- 13 -
B
A
C C
GB
ENGLISH
