The carburetor jetting can be modified as follows:
Remove fuel hose from carburetor inlet and pinch fuel hose so that no fuel can flow out of
the carburetor inlet.
Loosen both hose clamps at carburetor socket and silencer socket and remove carburetor.
Attention: When removing the carburetor always hold it in vertical position to avoid flowing out
Warning: Handle fuel only in well vented areas!
Warning: When handling fuel do not handle with open light or fire. Fuel and fuel vapours are
Warning: Fuel must not get in contact with hot engine parts or accessories – risk of
Attention: Do not spill fuel. Soak spilled fuel immediately with adequate absorbant material and
Hold carburetor over a fuel-proof and clean
container and remove plug screw (pos.27)
and gasket (pos.26).
Note:
Note:
Chose a main jet of the required size
(see Chart 1A or 1B).
Fit jet cup (pos.14) in the position shown on
the illustration, and main jet (pos.15) of the
required size (see Chart 1A or 1B).
Mount plug screw (pos.27) with gasket
(pos.26) and tighten it with manual force.
Note:
Seite/page 93/132
Downloaded from www.Manualslib.com
of fuel.
easily inflammable and explosive!
inflammation and explosion.
dispose of it environmentally friendly.
The fuel drained from
chamber can be refilled into the fuel
tank if it is not contaminated.
Remove main jet (pos.15) and jet cup
(pos.14).
The size of the main jet is stamped at
its front side.
When the carburetor is removed, the
position of the jet needle (3) can be
modified. The standard position of the
jet needle is at „position 2".
