Note:
Proceed as per following drawing and use the parts specified:
Drill a hole of 8.5 mm / 3.4 in. diameter at the 3 positions marked.
Fasten the seat in these 3 positions.
Drill the 4
Fasten the seat in this 4
Note:
Note:
Seite/page 105/132
Downloaded from www.Manualslib.com
The cuneiform washer (Pos. 4) is made of special plastic and has to be fitted
directly to the seat.
th
hole at the position left top (seen in driving direction).
th
position.
If you want to use the seat of another manufacturer pls. contact a ROTAX Service
Center.
The seat fastenings screws have to be checked regularly for tightness, as the
upholstery can settle after the first few operating hours and the screws may require
retightening.
