5.2.3. Brake fluid

The hydraulic circuit of the brake system is filled at the factory and checked for tightness.
The level of brake fluid in the fluid reservoirs
can be checked as follows:
Place vehicle on level surface.
Check brake fluid level at the minimum
– maximum marks. The level should be
between the two marks.
If the level is too low, refill with brake fluid.
Proceed as follows:
Open the respective fluid reservoir.
Remove the compensating diaphragm.
Refill with brake fluid.
Check level again.
Close the fluid reservoir.
Attention: If the vehicle is operated with insufficient brake fluid, the brakes may fail.
Note:
Note:
5.2.4. Brake pads
The brake pads are a safety relevant component
and should get particular attention. The brake
pads should have a minimum remaining lining
thickness of 1,5 mm / 0,06 in.
As long as the wear indicator grooves (pos. 1) are
still visible the lining thickness is within the wear
limit of 1,5 mm / 0,06 in.
Note:
Attention: Driving the vehicle with brake pads below the minimum thickness may cause
Seite/page 114/132
Downloaded from www.Manualslib.com
Depending on the thermical strain of the brake system, the brake fluid may become
discoloured. This however is no reason to change the brake fluid.
If you have to refill brake fluid frequently, check the hydraulic circuit for obvious
leakage. In case of leakage contact immediately a ROTAX Service Center.
Brake pads with less lining
thickness should immediately be
replaced by new ones.
sudden brake failure. There is the risk that the linings detach from the pads without
previous warning due to lack of adherence.
