4.8.2. Throttle pedal
The throttle pedal can be adapted to the ergonomical needs of the driver.
C) Adjustment of full throttle position
Adjust the pedal to your optimum position at full throttle.
Tighten the front stop (pos.2).
Adjust the throttle cable (pos.3) according to your needs.
D) Adjustment at idle position
Adjust the pedal to the position at idling.
Tighten the stop (pos.1).
Adjust the throttle cable according to your needs.
After adjustment of the stops adjust the length of the throttle cable and tighten it with a cable clamp
(pos.4).
Note:
For fine adjustment pls. use adjustment screw (pos.10) with lock nut (pos.9) on the carburettor
cover.

4.9. Seat

The ROTAX Kart RM1 was developed with a seat type TILLETT T8 1/4. It is recommended not to
exchange the seat for another brand.
If it should be necessary to exchange the seat installed for one of a different type or size,
procedure is as following:
All parts necessary for replacement (except the seat) are supplied with the vehicle.
Seite/page 104/132
Downloaded from www.Manualslib.com
Make sure the Bowden cable has some
play when the throttle is closed
otherwise when you start the engine the
throttle may be partly open and the
engine will not idle correctly.
