By turning the wheel (pos. 15) clockwise the opening r.p.m. of the exhaust valve is pushed
towards lower r.p.m.
By turning the wheel (pos. 15) counter-clockwise the opening r.p.m. of the exhaust valve is
pushed towards higher r.p.m.
Note:
Note:
Note:
Attention: The correct adjustment of the opening timing of the exhaust valve has to be
Attention: The adjustment wheel must never be actuated during driving.
Seite/page 121/132
Downloaded from www.Manualslib.com
By turning the adjustment wheel the opening r.p.m. can be modified only slightly
(approx. +/- 250 1/min). With the the basic adjustment of the exhaust valve made at
the factory this range is fully sufficient.
The opening of the exhaust valve can be clearly heard. With the higher exhaust
valve timing the exhaust system sounds higher in tone.
The exhaust valve should open during driving operation at 7.500 r.p.m.
determined during driving operation.
