Assembly and preparation

Fitting the handle

Fitting the sterilizable handle E
Immediately before an operation, fit the handle
under sterile conditions as follows:
1 Fit the handle (A) on the inner handle so that the
markers (B) line up.
68
B
A
2 Turn the handle (A) clockwise until the locking
mechanism (C) engages audibly.
3 Check that the handle is securely attached.
Turn the handle counterclockwise to do this.
WARNING
Risk of patient injury
The sterilizable handle can fall down into the
operating field if it is not engaged properly.
The handle must be checked for secure at-
tachment after it has been fitted to the inner
handle.
– To remove the handle, see "Disassembly" on
page 76.
Instructions for use Polaris Multimedia
C
A
