Motor-Umrichterzuordnungen - SEW-Eurodrive MOVIDRIVE modular Produkthandbuch

Projektierung
3

Motor-Umrichterzuordnungen

n Motor
N
–1
min
4500 CMP40S
CMP40M
CMP50S
CMP50M
CMP50L
CMP63S
CMP63M
CMP63L
CMP71S
CMP71M
CMP71L
CMP80S
CMP80M
CMP80L
CMP100S
CMP100M
CMP100L
CMP112S
CMP112M
CMP112L
CMP112H
CMP112E
6000 CMP40S
CMP40M
CMP50S
CMP50M
CMP50L
CMP63S
CMP63M
CMP63L
CMP71S
CMP71M
CMP71L
CMP80S
CMP80M
CMP80L
146
Produkthandbuch – MOVIDRIVE
M I M
0 0 pk
Nm A Nm
0.5 1.2 1.9
0.8 0.95 3.8
1.3 1.32 5.2
2.4 2.3 10.3
3.3 3.15 15.4
2.9 3.05 11.1
5.3 5.4 21.4
7.1 6.9 30.4
6.4 7.3 19.2
9.4 10.9 30.8
13.1 14.1 46.9
13.4 15.3 42.1
18.7 20.1 62.6
27.5 27.8 107
25.5 30 68.3
31 33.1 108
47 48.4 178.8
30 31.5 88
45 47 136
69 73 225
83 86 270
95 98 320
0.5 1.2 1.9
0.8 1.1 3.8
1.3 1.7 5.2
2.4 3 10.3
3.3 4.2 15.4
2.9 3.9 11.1
5.3 6.9 21.4
7.1 9.3 30.4
6.4 9.6 19.2
9.4 14.7 30.8
13.1 18.8 46.9
13.4 20 42.1
18.7 26.4 62.6
27.5 37.6 107
®
modular
I M I
max 0VR 0VR
A Nm A
6.1 – –
6.0 – –
7.0 1.7 1.7
13.1 3.5 3.35
19.5 4.8 4.6
18.3 4 4.2
32.4 7.5 7.6
41.4 10.3 10
38 8.7 9.9
57 13.7 15.9
87 21 22.5
73 18.5 21
103 27 29
159 44 44.5
111 36 42.5
154 47 50
251 70 72
112 43 45.5
168 68 72
275 107 114
335 123 128
385 150 156
6.1 – –
6.9 – –
9.0 1.7 2.2
17.1 3.5 4.4
26 4.8 6.1
23.4 4 5.4
41.4 7.5 9.8
55.8 10.3 13.5
50 8.7 13.1
76 13.7 21.5
115 21 30
95 18.5 27.5
135 27 38
215 44 60
m J
mot
-4 2
kg 10 kgm
1.3 0.1
1.6 0.15
2.3 0.42
3.3 0.67
4.1 0.92
4.0 1.15
5.7 1.92
7.5 2.69
7 3.04
8.4 4.08
11.4 6.18
12.8 8.78
16.5 11.9
21.4 18.1
19.8 19.59
24.8 26.49
34.6 40.24
38.4 74
46.2 103
62.56 163
70.43 193
78.2 222
1.3 0.1
1.6 0.15
2.3 0.42
3.3 0.67
4.1 0.92
4.0 1.15
5.7 1.92
7.5 2.69
7 3.04
8.4 4.08
11.4 6.18
12.8 8.78
16.5 11.9
21.4 18.1
