1 Firmware
Versionsnummer und Erstellungsdatum der Firmware
2 Aufbau des Barcodes
insgesamt 24 Ziffern 0,9 mm Modulbreite (Code 128 C)
Ziffer
Inhalt
Linker Barcode:
1 - 5
Testergebnis, dezimal (00000 - 65535)
6 - 8
Version (z.B. 203)
9 - 10
x + 4y + 32z
x = Schnittstelle:
y = Baudrate:
z = Protokoll:
11 - 12
Helligkeit min.
Rechter Barcode:
1 - 2
Helligkeit max.
3
x + 4y
x = Default-Lichtschranke:
y = Default-Druckmodus:
4
Angeschlossenes Gerät:
5
Speicherkartentyp: 0 = keine
6 - 7
Speicherkartengröße:
8
2y + 4z
y = Heizspannung OK: 0 = nein
z = Temperatur OK: 0 = nein
9 - 10
Heizstufenoffset (0 - 9 = -9 - +9)
11 - 12
Netzwerkadresse (00 - 25 = A - Z)
Apollo 3
0 = RS-232
1 = RS-422
2 = RS-485
3 = Centronics
0 = 1200
1 = 2400
2 = 4800
3 = 9600
4 = 19200
5 = 38400
6 = 57600
0 = keins
1 = RTS/CTS
2 = XON/XOFF
1 = Durchlicht
2 = Reflex unten
0 = Thermodruck
1 = Transferdruck
0 = Messer
1 = Spendesensor
3 = keins
4 = ext. Druckstart
1 = sRAM
2 = Flash
3 = EPROM
x*64 kByte
1 = ja
1 = ja
1 Firmware
Firmware version and generation date
2 Barcode test information structure
total of 24 numbers 0.9 mm module width (Code 128 C)
Number
Contents
Left-hand barcode:
1 - 5
test result, decimal (00000 - 65535)
6 - 8
version (e.g. 203)
9 - 10
x + 4y + 32z
x = interface:
y = baud rate:
z = protocol:
11 - 12
brightness minimum
Right-hand barcode:
1 - 2
brightness maximum
3
x + 4y
x = label edge sensor default:
y = printing mode default:
4
device connected:
5
type of memory
board:
6 - 7
size of memory board:
8
x + 2y + 4z
y = heater voltage OK: 0 = no
z = temperature OK:
9 - 10
heat level offset (0 - 9 = -9 - +9)
11 - 12
network address (00 - 25 = A - Z)
0 = RS-232
1 = RS-422
2 = RS-485
3 = Centronics
0 = 1200
1 = 2400
2 = 4800
3 = 9600
4 = 19200
5 = 38400
6 = 57600
0 = none
1 = RTS/CTS
2 = XON/XOFF
1 = see through gap
2 = bottom reflective
0 = thermal printing
1 = transfer printing
0 = cutter
1 = present sensor
3 = none
4 = ext. printing start
0 = none
1 = sRAM
2 = Flash
3 = EPROM
x*64 kByte
1 = yes
0 = no
1 = yes
15
