Registerbelegung PROFINET-Interface

11.1 Eingänge der Anlage
Reg. Profinet-
Adr. Adresse
0 Status 1 0.0
0.1
0.2
0.3
0.4
0.5
0.6
0.7
1.0
1.1
1.2
1.3
1.4
1.5
1.6
1.7
1 Status2 2.0
2.1
2.2
2.3
2.4
2.5
2.6
2.7
3.0
3.1
3.2
3.3
3.4
3.5
3.6
3.7
106
Name Funktion/Beschreibung
1 bit
1 bit Mfail Measuring Failed
1 bit MDone
Measuring Done
1 bit MErr Measuring Error
1 bit MOK Measuring OK
1 bit SOP Shutter Open
1 bit SCL Shutter Closed
1 bit MirPro Mirror Process
1 bit MirFib Mirror Fibre
1 bit OptLoad Optical Load Critical
1 bit WOK Water OK
1 bit ConfErr Confirmation Key Error
1 bit ConfReq Confirmation Key Request
1 bit LasON Switch Laser on
1 bit ScrptRun Script running
1 bit
1 bit WarnTFO Group Warning Temperature, Fluids, Optics
1 bit WarnLDS Group Warning LaserDiagnoseSoftware
1 bit ErrTFO Group Error Temperature, Fluids, Optical
Load
1 bit ErrMOE Group Error Mechanics, Optics, Electronic
1 bit ErrLDS Group Error LaserDiagnoseSoftware
1 bit
1 bit
1 bit PwrSelFlg Power Select Flag
1 bit
1 bit AbrtPgrs Abort in Progress
1 bit
1 bit
1 bit
1 bit
1 bit
1 bit
HP-MSM-I PROFINET
®
8 byte
Status_
RequestModul
