primes HP-MSM-I Originalbetriebsanleitung Seite 107

HP-MSM-I PROFINET
®
Reg. Profinet-
Adr. Adresse
2 Select 4.0
4.1
4.2
4.3
4.4
4.5
4.6
4.7
5.0
5.1
5.2
5.3
5.4
5.5
5.6
5.7
3 CommandRun 6.0
6.1
6.2
6.3
6.4
6.5
6.6
6.7
7.0
7.1
7.2
7.3
7.4
7.5
7.6
7.7
Revision 02/2018 DE
Name Funktion/Beschreibung
1 bit
1 bit
1 bit
1 bit
1 bit
1 bit
1 bit
1 bit
1 bit conf 1/2 robot configuration 1/2
1 bit conf 3/4 robot configuration 3/4
1 bit SelPwr05 5% of maximum Power selected
1 bit SelPwr10 10% of maximum Power selected
1 bit SelPwr20 20% of maximum Power selected
1 bit SelPwr40 40% of maximum Power selected
1 bit SelPwr80 80% of maximum Power selected
1 bit SelPwr100 100% of maximum Power selected
1 bit
1 bit
1 bit OPS_Rn Open Shutter Running
1 bit CLS_Rn Close Shutter Running
1 bit MStaRn Measuring Start Running
1 bit
1 bit
1 bit
1 bit NxtPGRn Next Protection Glass Running
1 bit NxtClPGRn Next Clean Protection Glass Running
1 bit
1 bit
1 bit
1 bit
1 bit
1 bit
