8.8 Wiring Combinations

1Ø+NEUTRAL
1Ø SPLIT
PHASE
1Ø IT NO
NEUTRAL
3Ø WYE
3Ø DELTA
3Ø IT
3Ø HIGH LEG
3Ø OPEN LEG
2-ELEMENT
2 -ELEMENT
1
2
Measurement range
0.0~5.0%
0.0~20.0%
-360°~ 0°
-360°~ 0°
Measurement range
±6000Vpk
10~1000Vrms
50μs
20kS/s
Measurement range
0~3000Arms
6s~32min settable
Single phase with neutral
Split phase
Single phase system with two phase voltages without neutral
3-phase 4-wire system, Y type
3-phase 3-wire system delta (Delta)
3-phase Y type without neutral
4-wire 3-phase delta system (Delta) with center tapped high leg
Open-delta (Delta) 3-wire system with two transformer windings
3-phase 3-wire system without current sensor on phase L2/B (2
Watt meter method)
3-phase 4-wire system without voltage sensor on phase L2/B
Resolution
0.1%
0.1%
1°
1°
Resolution
1V
1V
Resolution
0.1
10ms
-90-
Accuracy
±0.5%
±1%
±2 characters
±5 characters
Accuracy
±15%
±2.5%
Accuracy
±1%±5 characters
±20ms
