Flicker (*)
Dips (*)
Swells (*)
Interruption (*)
Rapid Voltage
Change (*)
Unbalance
Frequency
(*): Setups are also valid for measuring mode.

6.7. Using Memory and PC

The Analyzer can save screens and data into its memory, and the users can view,
delete and copy them. The Analyzer can also be connected with a PC, through which
the remote control of the Analyzer is available.
 Using memory
The Analyzer has a built-in 8G TF card to store data the users saved. The Analyzer
can save screenshot of current screen, and data set of current measurement too.
 SAVE interface
The 【SAVE】 key accesses save interface, select screenshot or data set as save
type, the name of the file to be saved is editable.
Press 【F1】 to switch save type. Use left/right arrow keys to move the cursor, and
up/down keys to change name, press【F4】SPACE to erase current selected
character, the cursor moves to its next position. Press 【F5】to save the setting and
return to previous interface.
Weighing curve (lamp type). 2 probability percentages
(100% and adjustable): adjustable percentage with
adjustable upper limit.
Threshold, hysteresis, allowed number of week.
Threshold, hysteresis, allowed number of week.
Threshold, hysteresis, allowed number of week.
Voltage tolerance, steady time, minimum step, minimum
rate, allowed number of week.
2 probability percentages (100% and adjustable):
adjustable percentage with adjustable upper limit.
2 probability percentages (100% and adjustable): each
with adjustable upper and lower limits.
-65-
