8.5 Display Mode

Waveform display
Phasor Display
Table Screen
Trend Display
Events Table Display
Bar Graph Display
8.6 Measuring Modes and Parameters
Measurement mode
Oscilloscope
Voltage/current/frequency Vrms, Vpk, Vcf, Arms, Apk, Acf, Hz
Dips&Swells
Harmonic
Power and energy
Flicker
Unbalance
4 voltages and 4 currents signal waveforms can be
displayed synchronously, displayable under Scope and
Transient modes.
Intuitively view voltage and current phases of each
phase (Displayable under Unbalance)
Displayable under voltage/current/frequency, harmonic,
power and energy, flicker, unbalance modes.
Display Trend record of measurement parameters
changes over
voltage/current/frequency, power and energy, dips and
swells, inrush current, flicker, monitoring modes)
Display information of events exceeding limits value
(Displayable under Dips&Swells, Transient, Inrush
current, Monitoring modes.)
Harmonic and interharmonic bar graph display mode is
more intuitive (Displayable under harmonics and
monitoring modes)
Measured parameters
Vrms, Arms, Vcursor, Acursor, Hz
Vrms1/2, Arms1/2, capture up to 1000 events, include
date, time, duration, magnitude and phase mark, and
threshold is programmable settable.
1-50, harmonic voltage, THD voltage, harmonic current,
THD current, interharmonic voltage, interharmonic
current
W, VA, VAR, power factor, shift power factor, Arms,
Vrms, kWh, kVah, kVARh
Pst (1 minute), Pst, Plt, PF5
Vneg, Vzero, Aneg, Azero, Vfund, Afund, Hz, V phase
angle, A phase angle
-87-
time (Displayable under
