Elektrische Anschlussübersicht - Danfoss FCP 106 Programmierungshandbuch

Einführung
1 1
1.6 Elektrische Anschlussübersicht
3 Phase
power
input
+10Vdc
0-10Vdc-
0/4-20 mA
0-10Vdc-
0/4-20 mA
Abbildung 1.1 Elektrische Anschlussübersicht
8
Programmierungshandbuch
L1
L2
L3
PE
50 (+10V OUT)
53 (A IN)
54 (A IN)
55 (COM A IN/OUT)
42 0/4-20mA A OUT / DIG OUT
45 0/4-20mA A OUT / DIG OUT
12 (+24V OUT)
Group 5-*
18 (DIGI IN)
19 (DIGI IN)
20 (COM D IN)
27 (DIGI IN)
29 (DIGI IN)
Danfoss A/S © Ver. 08/2014 Alle Rechte vorbehalten.
Bus ter.
ON=Terminated
OFF=Unterminated
24V (NPN)
0V (PNP)
24V (NPN)
0V (PNP)
Bus ter.
24V (NPN)
RS-485
(N PS-485) 69
0V (PNP)
Interface
24V (NPN) (P RS-485) 68
0V (PNP)
(Com RS-485) 61
U
V
W
PE
Motor
T1 Thermistor
located in
motor
T2
UDC-
UDC+
relay 2
06
240V AC 3A
05
04
relay 1
03
240V AC 3A
02
01
RS-485
(PNP)-Source
(NPN)-Sink
MG03N103
