Elektrische Anschlussübersicht - Danfoss VLT CDS 803 Kurzanleitung

Kurzanleitung
1 1
1.3.9 Elektrische Anschlussübersicht
3-phase
power
input
+10 V DC
0-10 V DC-
0/4-20 mA
0-10 V DC-
0/4-20 mA
Abbildung 1.11 Anschlussdiagramm des Grundgeräts
10
®
VLT Compressor Drive CDS 803
L1
L2
L3
PE
50 (+10 V OUT)
53 (A IN)
54 (A IN)
55 (COM A IN/OUT)
42 0/4-20 mA A OUT / DIG OUT
45 0/4-20 mA A OUT / DIG OUT
12 (+24 V OUT)
18 (DIGI IN)
19 (DIGI IN)
20 (COM D IN)
27 (DIGI IN)
29 (DIGI IN)
Danfoss A/S © 12/2015 Alle Rechte vorbehalten.
UDC+
Bus ter.
ON=Terminated
OFF=Unterminated
24 V (NPN)
O V (PNP)
24 V (NPN)
O V (PNP)
Bus ter.
24 V (NPN)
RS485
(N RS485) 69
O V (PNP)
Interface
(P RS485) 68
24 V (NPN)
O V (PNP)
(Com RS485 ) 61
U
V
W
PE
Motor
UDC-
Not present on all power sizes
relay 2
06
240 V AC 3 A
05
04
relay 1
03
240 V AC 3 A
02
01
RS485
Do not connect shield to 61
(PNP)-Source
(NPN)-Sink
MG18M203
