Elektrische Anschlussübersicht - Danfoss VLT DriveMotor FCP 106 Projektierungshandbuch

Produktübersicht
2.1.3 Elektrische Anschlussübersicht
L1
L2
3-phase
L3
power
input
50 (+10 V OUT)
+10 V DC
0–10 V DC -
53 (A IN)
0/4–20 mA
0–10 V DC -
54 (A IN)
0/4–20 mA
55 (COM A IN/OUT)
42 0/4–20 mA A OUT/DIG OUT
45 0/4–20 mA A OUT/DIG OUT
12 (+24 V OUT)
18 (DIGI IN)
19 (DIGI IN)
20 (COM D IN)
27 (DIGI IN)
29 (DIGI IN)
PROFIBUS
Abbildung 2.4 Elektrische Anschlussübersicht
MG03M203
Projektierungshandbuch
PE
Group 5-*
24 V (NPN)
0 V (PNP)
24 V (NPN)
0 V (PNP)
24 V (NPN)
0 V (PNP)
24 V (NPN)
0 V (PNP)
MCM
Danfoss A/S © 06/2016 Alle Rechte vorbehalten.
U
V
W
PE
Located in
motor block
T1
T2
UDC-
UDC+
relay 2
06
05
04
relay 1
03
02
01
Bus ter.
ON=Terminated
OFF=Unterminated
Bus ter.
RS485
(N RS485) 69
Interface
(P RS485) 68
(Com RS485) 61
Motor
Thermistor
located in
motor
240 V AC 3A
240 V AC 3A
RS485
(PNP)-Source
(NPN)-Sink
13
2 2
