REPLACING THE FRONT BRAKE PADS

The procedure for replacing the brake
pads is provided only for information.
We recommend having the operation
performed by a BETAMOTOR authorized
workshop.
ALP 4.0 FRONT BRAKE
Follow these steps to replace the pads:
• Loosen the two screws A and remove the
brake caliper.
• Loosen the two screws B.
B
• Extract the brake pads.
• To refi t the parts, follow the reverse pro-
cedure, using blockage-threads on the
screws A.
WARNING:
When removing the front brake caliper,
take care not to damage sensor C.
To avoid braking problems, take special
care in ensuring that the screws are refi t-
ted properly.
Whenever the brake disc is removed, ap-
ply blockage-threads to the screws when
refi tting.
