REPLACEMENT OF INDICATORS AND
REAR LIGHT
A
In both models (ALP 4.0 and M4), the
indicators and rear lights have a light LED.
In the event of a breakdown, replace the
whole indicator as follows:
FRONT INDICATORS
Unscrew the nut A inside the cover, which
matches the damaged indicator.
Pull out the light unit and disconnect it from
the electric wire.
Connect the new indicator, fi t it back onto
its rest.
Screw the nut A.
REAR INDICATORS
Unscrew the nut B under the rear fender,
which matches the damaged indicator.
B
Pull out the light unit and disconnect it from
the electric wire.
Connect the new indicator, fi t it back onto
its rest.
Screw the nut B.
C
Rear light
Unscrew the two screws C and remove
the rear light D.
Disconnect the light wire by removing the
back tail and back handles as described
on page 137.
D
