FUME COLLECTING TUBE

Fume collecting tube A is located on the
left side of the vehicle, next to the shock
absorber, and comes out of the lower part
of the fi lter box. It is designed to collect the
fumes produced by the engine oil. Should
you fi nd some oil in the tube, remove the
cap at the lower end of the tube and drain
the oil, or the mixture of oil and petrol,
into a suitable container. Disposal is to be
made according to the regulations in force.
Note
Empty the fume collecting tube every
3,000 km.
BRAKE PUMP OIL - BLEEDING THE BRA-
C KES
Front brake
Check that oil is present by looking through
oil level sight B. The minimum oil level
D
should never be lower than the mark on
sight B. To restore the oil level, loosen the
two screws C, lift cover D and pour in
B
fresh oil.
Keep the motor in a stable vertical position,
possibly blocking the handle-bar, so as to
avoid the brake oil from spilling out.
