Power frequency (50/60 Hz)
IEC 61000-4-8
Note: UT is the A.C. mains voltage prior to application of the test level.
Guidance and manufacturer's declaration — electromagnetic immunity
Eclipse is intended for use in the electromagnetic environment specified below. The customer or the user of Eclipse should assure that it is used
in such an environment,
Immunity test
Conducted RF
IEC / EN 61000-4-6
Radiated RF
IEC / EN 61000-4-3
NOTE1 At 80 MHz and 800 MHz, the higher frequency range applies
NOTE 2 These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflection from structures,
objects and people.
(a)
Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile radios, amateur radio,
AM and FM radio broadcast and TV broadcast cannot be predicted theoretically with accuracy. To assess the electromagnetic environment due
to fixed RF transmitters, an electromagnetic site survey should be considered. If the measured field strength in the location in which Eclipse is
used exceeds the applicable RF compliance level above, the Eclipse should be observed to verify normal operation, If abnormal performance is
observed, additional measures may be necessary, such as reorienting or relocating Eclipse.
(b)
Over the frequency range 150 kHz to 80 MHz, field strengths should be less than 3 V/m.
3 A/m
IEC / EN 60601
test level
3 Vrms
150kHz to 80 MHz
3 V/m
80 MHz to 2,5 MHz
3 A/m
Compliance level
3 Vrms
3 V/m
Power frequency magnetic fields should
be at levels characteristic of a typical
location in a typical commercial or
residential environment.
Electromagnetic environment –
guidance
Portable and mobile RF
communications equipment
should be used no closer to any
parts of Eclipse, including
cables, than the recommended
separation distance calculated
from the equation applicable to
the frequency of the transmitter.
Recommended separation
distance
=
d
1
2 ,
P
=
d
2 , 1
P
80 MHz to
800 MHz
=
d
2
3 ,
P
800 MHz to
2,5 GHz
Where P is the maximum output
power rating of the transmitter in
watts (W) according to the
transmitter manufacturer and d
is the recommended separation
distance in meters (m).
Field strengths from fixed RF
transmitters, as determined by
an electromagnetic site survey,
(a) should be less than the
compliance level in each
frequency range (b)
Interference may occur in the
vicinity of equipment marked
with the following symbol:
