6.4 General menu navigation

The control system is operated via touch display. For general, the individual menu navigation options are
described below.
The following elements are used for operation:
• You can scroll through the menu by pressing the arrow buttons on the right edge of the screen.
• Access the corresponding menu by pressing on the menu item.
• You can get to the next highest menu level by pressing the two arrows one behind the other.
• The user can adjust the parameters highlighted in grey by pressing
the white arrow. If no peaks are offered, the user must press on
the parameter highlighted in grey to change it.
• Pressing the OK button accepts the changes made to the parameters.
If you do not press the OK button and leave the submenu by pressing
the two arrows one behind the other (Back), the old values continue to apply,
and the changes have not been accepted.

6.5 Start screen

The start screen for the system is shown in figure 1.
• ON/OFF:
Turn the control function on and off by pressing the left ON/OFF button.
When it is on, the button is green. When it is off, the button is blue.
• AUTO/CONT:
Pressing the middle button switches the control system between automatic mode (filter run time
according to switching times) and continuous operation mode. In automatic mode, the button
is blue. In continuous operation mode, the button is orange.
DURATION
25.0°C
pH value: 8.13 Chlorine: 0.55 mg/l
Figure 1: Start screen
