Pool control system Control 1.3 / Operation
• DATE/OFF:
Turn the control function on and off by pressing the left ON/OFF button.
When it is on, the button is green. When it is off, the button is blue.
• AUTO/CONT:
Pressing the middle button switches the control system between automatic mode (filter run time
according to switching times) and continuous operation mode. In automatic mode, the button is
blue. In continuous operation mode, the button is orange.
• SETTINGS:
Pressing the right button with the screwdriver symbol gets the user into the settings menu.
• DATE/TIME:
The day, the date and, beneath that, the time are displayed in the top right corner of the start
screen.
• ERROR MESSAGES:
If there are error messages, this will be shown through a red warning triangle in the top left corner.
The user can access the error messages by pressing on the warning triangle.
• STATUS SYMBOLS (filter pump, fresh water, auxiliary heating, solar heating):
On the left, next to the date, you'll find individual status symbols, which are only displayed if the
corresponding peripheral devices and their functions have been chosen. A grey symbol shows
that the peripheral device in question is currently not active. A coloured symbol shows that the
peripheral device is active. In addition, the colour of the pump symbol shows the current speed.
The following symbols are available:
Symbol Explanation
Green, one wave: The pump is at low speed (ECO)
Blue, two waves: The pump is at normal speed
Yellow, three waves: The pump is at its highest speed
Orange with exclamation mark: The pump is in FORCED ON mode at normal speed
Red with exclamation mark: The pump is in FORCED OFF mode and stops as a result
Red, with waves: The heating is active due to the set temperature.
Yellow, with sun: Solar mode is active due to the set temperature.
Blue waterdrop: The fresh water backfeed is active due to the requirements for the float
switch or the hanging electrodes.
Grey symbol: The respective function is currently not active.
