Code
Alarm code
Pre-alarm
21 121 Bemf error
22 122 Internal communication error
23 123 Overcurrent
24 124 No load
25 125 Incorrect voltage
26 126 Error on start-up
27 127 IPM protection error
28 128 EEPROM error
29 129 Compressor stall
30 130 No communication
31 131 PFC Module
32 132 Cooling fin overheating
Over current in acceleration
33 133
mode
Over-current at constant
34 134
speed
Over current in deceleration
35 135
mode
36 136 Under-voltage on the DC Bus (cod. APY 5)
37 137 DC Bus over-voltage
PFC Converter Fault Error in
40 140
the PFC module
Over current in acceleration
41 141
mode
42 142 Overload
Over-current at constant
43 143
speed
Over current in deceleration
44 144
mode
Over current in acceleration
45 145
mode
46 146 No communication
Cooling fin temperature
47 147
sensor error
51 151 Anomalous condition
54 -- Cycle reverse valve faulty
55 155 Water inlet high temperature
Cycle reverse due to high
-- 156 temperature of the pressing
line gas
Causes
Error in detection of the back emf. This error is returned by the in-
verter control board and is linked to compressor peak problems
(longertek 4 code or longertek 20 code)
The inverter control board has internal communication problems
(longertek 5 code)
Excess current absorption by compressor (longertek 6 code)
The compressor does not absorb enough current, it may turn in
idle mode (longertek 7 code)
The inverter control board indicates incorrect bus voltage (lon-
gertek 8 code)
The inverter control board indicates incorrect start-up of the PMSM
motor (longertek code 9)
Error on the IGBT (longertek 12 code)
Eeprom error on the inverter control board (longertek 13 code)
Cod. longertek 16
The inverter control board does not respond. It may not be pow-
ered or the serial cable could be disconnected or the A and B sig-
nals reversed
PFC inverter module error (longertek 23 code)
(cod. APY 1)
Hardware error (cod. APY 2)
Hardware error (cod. APY 3)
Hardware error (cod. APY 4)
(cod. APY 6)
Software error (code APY 9)
Software error (code APY 10)
(cod. APY 11)
Software error (code APY 12)
Software error (code APY 13)
(cod. APY 14)
(cod. APY 15)
(cod. APY 16)
Protection frequency against over-current and overheating re-
duced. (code APY 20)
The cycle reverse valve could be faulty or broken. (see paragraph
8.4)
The water inlet temperature has exceeded the set_installer (H)
parameter value. Probable boiler presence on same plant. At the
third intervention of the pre-alarm, the machine goes into alarm
mode and blocks
This pre-alarm indicates the intervention of defrosting due to cycle
reverse without having respected the times between cycle revers-
es. Cycle reverse has been triggered by the pressing line gas high
temperature partialisation threshold being exceeded, set_factory
(6)-set_factory (4) = default 130°. This pre-alarm does not cause
compressor stop and does not have a limited number of interven-
tions
