MODUCONTROL
25/01 6343841_06
Index - String MIN value MAX value
0 StA
0
Index - String MIN value MAX value
-20 °C
1 StF
Index - String MIN value MAX value
1 °C
2 bnF
Index - String MIN value MAX value
3 StC
25 °C
Index - String MIN value MAX value
4 bnC
1 °C
Index MIN MAX
- String value value
0 3
5 CSt
52
Setting of operational mode (HOT/COLD)
This parameter identifies the functioning mode set for the unit:
- Set value = 0 - Cooling mode;
1 - Set value = 1 - Heating mode;
In cooling only units, this parameter is displayed but it cannot be modified.
In software versions prior to 3.75, to make the season change the unit must be in standby.
Setting of cooling temperature
26 °C This parameter indicates the value of the work setting active in cooling mode.
Setting of proportional cooling band
This parameter indicates the proportional band applied to the cooling set; this band
produces the optimised management of the compressor, only switching it on if the
20 °C inlet/outlet water temperature (depending on the type of control set by parameter
(0) in the installer menu) is greater than the cooling work set (parameter (1) user
menu) plus the value of this parameter.
Setting heating mode temperature set
This parameter indicates the active work set value in the heating mode. This param-
eter is displayed in the cooling only units but cannot be modified.
(*):
(*)
- the maximum limit can be configured via the parameter (t) of the installer menu;
- if the parameter (8) of the installer menu is set at 4, the maximum limit becomes
70°C in order to allow insertion of a set-point for boiler adjustment;
Setting of proportional heating band
This parameter indicates the proportional band applied to the heating set; this band
produces the optimised management of the compressor, only switching it on if the
inlet/outlet water temperature (depending on the type of control set by parameter
20 °C
(0) in the installer menu) is less than the heating work set (parameter (3) user menu),
minus the value of this parameter. In cooling only units, this parameter is displayed
but it cannot be modified.
Settings made on the basis of outside temperature
Parameter function
This setting activates the algorithm of com-
pensation of the work setting:
In cooling mode, the work setting is calculated
automatically on the basis of the outside tem-
perature, following the logic highlighted in the
diagram.
Parameter function
Parameter function
Parameter function
Parameter function
Parameter function
In heating mode, the work setting is calculated
automatically on the basis of the outside tem-
perature, following the logic highlighted in the
diagram.
