MODUCONTROL
25/01 6343841_06
Code
Alarm code
Pre-alarm
Reading error of the DHW
57 157
control board remote probe
Outdoor air temperature
58 158
probe reading error
Inlet water probe no
59 159
condenser (ONLY WRL)
Output water probe no
60 160
condenser (ONLY WRL)
61 161 Overcurrent
62 162 Compressor motor overload
63 163 Overvoltage
64 164 Undervoltage
65 165 Drive overheating
66 166 Drive underheating
67 167 Hardware over-current
68 168 Compressor overheating
69 169 Reserved
70 170 CPU error
71 171 Default parameters
72 172 DC bus ripple
No communication between
73 173
inverter and uPC
74 174 Drive temperature sensor fault Carel Inverter
75 175 Self-configuration failed
76 176 Inverter drive disabled
77 177 Motor phases error
78 178 Cooling fan Inverter faulty
79 179 Speed fault
80 180 PFC fault
81 181 PFC overload trip
82 182 Input voltage error
83 183 Generic inverter error
84 184 Probe B1 fault (uPC)
85 185 Probe B2 fault (uPC)
86 186 Probe B3 fault (uPC)
87 187 Probe B4 fault (uPC)
88 188 Probe B5 fault (uPC)
89 189 Probe B6 fault (uPC)
90 190 Probe B7 fault (uPC)
91 191 High pressure alarm (uPC)
92 192 Low pressure alarm (uPC)
Gas high temperature alarm
93 193
pressing line (uPC)
Pressure differential lower
94 194
than that specified (uPC)
Compressor start-up failed
95 195
(uPC)
Time exceeding operational
96 196
limits alarm (uPC)
97 197 Super Heat low alarm (uPC)
98 198 MOP alarm (uPC)
Low intake temperature alarm
99 199
(uPC)
EVD EVO alarm: Evotunes
200 300
alarm (uPC)
74
Causes
This pre-alarm indicates a remote probe fault or a communication
problem with the DHW control board. The alarm is only active if
the parameter (0)=2 or the parameter (8)=4 in the menu with
password = 30
This pre-alarm indicates an outdoor air temperature probe fault
when the DCP is present or the machine is in heat pump mode.
This pre-alarm indicates a condenser inlet water temperature
probe fault
This pre-alarm indicates a condenser outlet water temperature
probe fault
Carel Inverter
Carel Inverter
Carel Inverter
Carel Inverter
Carel Inverter
Carel Inverter
Carel Inverter
Carel Inverter
Carel Inverter
Carel Inverter
Carel Inverter
Carel Inverter
Carel Inverter
Carel Inverter
Carel Inverter
Carel Inverter
Carel Inverter
Carel Inverter
Alarm that occurs with PFC enabled while the bus DC is very low
This alarm will no longer be present in the new firmware versions
When the power supply drops below 170 V with engine running
Carel Inverter, carel modbus address 213
Control wiring
Control wiring
Control wiring
Control wiring
Control wiring
Control wiring
Control wiring
Control wiring
Control wiring
Control wiring
Control wiring
Control wiring
Control wiring
Control wiring
Control wiring
Control wiring
Control wiring
Note
