6.1 Dimensions
6.1.1 Dimensions of the unit body
C
Fig. 5 External dimensions and size of air outlet opening (unit: mm)
Product Type
AF2-CF 36-1 – AF2-CF 56-1
AF2-CF 71-1 – AF2-CF 90-1
AF2-CF 112-1 – AF2-CF 140-1
Table 3
6.1.2 Dimensions of the gas/liquid pipe
Model AF2-CF 36-1 –
AF2-CF 56-1
Gas side (F)
Liquid side (H)
Air Flux – 6721876663 (2023/12)
B
A
1069
1284
1649
Copper pipe for air conditioner
Ø [mm]
AF2-CF 71-1 – AF2-CF
140-1
12.7 15.9
6.35 9.52
A
D
B C D E
674 234 984 221
674 234 1199 221
674 234 1565 221
Installation
F
G
H
E
0010053494-001
F G
see Ø 25 see below
below
Ø 25
Ø 25
H
