Kemper KemJet Betriebsanleitung Seite 92

B 1853 [73.0]
C 1413 [55.6]
D 2110 [83.1]
E 2510 [98.8]
F 355 [14.0]
G 1146 [45.1]
Tab. 42: Maßtabelle 998701372 (998800407, 998800461)
Abb. 55: Maßblatt 998701371 (998800401, 998800462)
Symbol Abmessung mm [in]
A 1413 [55.6]
B 1913 [75.3]
C 1864 [73.4]
D 2110 [83.1]
E 2510 [98.8]
F 450 [17.7]
15028844-00
I 706 [27.8]
J 225 [8.9]
K 355 [14.0]
L 1175 [46.3]
N 484 [19.1]
O 1347 [53.0]
Symbol Abmessung mm [in]
H 1776 [69.9]
I 1157 [45.6]
J 235 [9.3]
K 450 [17.7]
L 1616 [63.6]
N 484 [19.1]
