Kemper KemJet Betriebsanleitung Seite 162

Pos. Description
1 Cover plate
2 Maintenance cover
Depending on the product variant, the filter change is carried out from the
front or from above. The filters in the front two rows can be changed from
the front.
For product variants with 3 or 4 rows of filter cartridges, the filter change
must always be carried out from above.
WARNING
Entry/access to the maintenance area is prohibited!
7.2.5 Filter replacement from the front
Perform the filter replacement as follows:
1. Disconnect the product from the mains supply and compressed air
network and allow any stored compressed air to escape from the
system.
2. Secure the product with a padlock to prevent unintentional restarting.
15028844-00
Fig. 100: Access to the filter cartridges
Pos.
3
4
Tab. 80: Access to the filter cartridges
Fig. 101: Changing filters
- 162 -
Description
Filter cartridge
Filter cartridge mounting
EN
