Kemper KemJet Betriebsanleitung Seite 168

Pos. Description
3 Filter cartridge
Tab. 85: Changing filters – removing the filter mounting
8. As shown in the illustration, remove the four hexagon bolts of the filter
mounting (Pos. 4).
9. Lift the filter mounting (Pos. 4) + filter cartridge (Pos. 8) out of the
product using a lifting device.
Fig. 108: Changing filters – removing the filter cartridge
10. Loosen the hexagon nut (Pos. 5) in the lower area of the filter cartridge
(Pos. 3), but do not remove it yet.
11. Carefully place the disposal bag (Pos. 6) over the filter cartridge (Pos. 3)
without disturbing dust particles.
12. Hold the filter cartridge (Pos. 3) and completely undo the hexagon nut
(Pos. 5) and let them fall together with the sealing washer into the
disposal bag (Pos. 6).
13. Pull the disposal bag with the contaminated filter cartridge downwards
from the rotation nozzle. Seal the disposal bag airtight and dispose of it
in accordance with the applicable regulations.
15028844-00
Pos. Description
4 Filter holder
- 168 -
EN
