No.
Description
1
Condensate drain valve for
compressed air vessel
2
Main block valve
compressed air supply
3
Pressure regulating
button compressed air
vessel
4
Lowering valve,
compressed air vessel
5
Connection plug, pressure
switch compressed air
vessel
1. Connecting the inlet-side connection box
Now fit the inlet-side connection box to the product. The necessary
bolts are provided in a bag inside the product. The connection box can
be fitted to the left-hand or right-hand side of the product depending
on local conditions. Close off the connection panel opening not selected
with the end cap provided.
2. Connecting to the compressed air supply
Now connect an on-site compressed air hose with an internal diameter
of 9 mm. To do this, the hose is pressed onto the grommet and fixed
with a band clamp. The hose and band clamp are not included in
delivery.
3. Adjusting the operating pressure
The pressure at the compressed air maintenance unit has been pre-set
to 5–6 bar by the manufacturer, but must be readjusted on site.
4. Adjusting the lifting device/dust collection container pressure
Also check that the specified value of 2.5 bar has been set on the
compressed pressure regulator. Readjustment may be necessary. The
value may not exceed 3.0 bar.
5. Connecting the power supply
Now connect the product with a CEE connector plug. The CEE plug
included in the scope of supply. When doing so, ensure that the feed
line is correctly fused and that the correct phase rotation direction has
15028844-00
No.
6
7
8
9
10
Tab. 56: Compressed air unit
- 127 -
Description
Pressure switch, dust
collection container
monitoring
Compressed air regulator
for dust collection
container lifting device
Pressure gauge lifting
device dust collection
container
Pressure gauge
compressed air vessel
Condensate drain valve for
compressed air
maintenance unit
EN
