32.2 Cable holder for M2Smart
Cable holder for the wall bracket of the M2Smart
holder is attached using the four M6 screws of the wall bracket. The screws are not included in the scope of
delivery.
Figure 38: Cable holder M2Smart
Material
Mounting
Dimensions
Weight
Table 28: Technical data for cable holder
®
32.3 M2Smart Screen Protection Film 10.1-Inch/Low Reflection
Display protection film with anti-reflective coating for the M2Smart
extremely robust polymer composite. Anti-fingerprint technology, ultra-thin, >3H surface hardness.
Consisting of:

Anti-reflective display protection films for M2Smart

Mounting kit for screen protection film
Bedien-Projektierungshandbuch _M2Smart
®
HMI10 Wired
®
HMI10 Wired
Technical Data
Sheet steel, painted deep black (RAL 9005)
The cable holder is attached using the four M6 screws of the wall bracket
Approx. 274 x 100 x 75 mm (L x W x H)
Approx. 670 g
®
