22.4 Technical Data for M2Smart
Supply
Housing
Protection Class
Operating
Temperature
Storage Temperature
Rel. Humidity
Device Dimensions
Weight
Display
Touchscreen
Keyboard/Keys
Camera*
RFID/NFC
(optional)
Processor
Memory
Operating System
Interfaces
Accessories
Table 19: Technical data
6
Registered trademark – Android
Bedien-Projektierungshandbuch _M2Smart
®
HMI10 Wired
Technical Data
15 W, 12 V / 24 V (+/- 15 %) DC
ABS/PC
IP54
-20 °C to 50 °C/-4 °F to 122 °F
Operation to -20 °C/-4 °F in cold store or outdoors is permissible.
Condensation in the device must be avoided.
-20 °C to 60 °C/4 °F to 140 °F
5 % - 90 % non-condensing
196 x 333 x 93 mm (L x W x H) with enabling switch
196 x 333 x 64 mm (L x W x H) without enabling switch
Approx. 1.650 g with enabling switch, without cable
Approx. 1.450 g without enabling switch, without cable
10.1" IPS color display with LED backlight,
1280 x 800 pixels, 500 cd/m
3 status LEDs
Capacitive touch, non-glare hard coating (3H),
One "On/Off" key (black) and one freely programmable top key (orange)
5 MP auto-focus camera with illumination
* Not active in the current device
Reader/writer mode, peer to peer mode, card emulation
ISO14443A/B, ISO15693, MIFARE/DESFire, Sony FeliCa
NXP i.MX8M Mini,
4x Cortex A53 (4x 1.8 GHz) and 1x Cortex M4 (1x 400 MHz)
16 GB Flash, 4 GB RAM
Optionally available: 32 GB Flash
TM 6
Android 9.0
WLAN according to IEEE802.11a/b/g/n/ac/d/h/e/i/r/w/v (2.4 GHz/5 GHz)
as well as BT-compatible short-range radio,
Integrated loudspeaker
Wall bracket for M2Smart
Cable holder for M2Smart
®
M2Smart screen protection film 10.1-inch/low reflection
®
M2Smart screen protection film 10.1-inch
TM
- Android is a trademark of Google LLC
®
