ACD GRUPPE M2Smart HMI10 Wired Projektierungshandbuch Seite 61

®
Figure 30: M2Smart HMI10 Wired sample circuit
A better overview of the pin assignment can be found in section 22.7.2 Pin Assignment in table 22.
®
25 Features of the M2Smart HMI10 Wired
25.1 Camera
®
There is a 5 MP auto-focus camera with flash/lighting on the rear side of the M2Smart HMI10 Wired.
®
The camera function is not activated in the current version of the M2Smart HMI10 Wired.
25.2 WLAN/BT-Compatible Short-Range Radio
WLAN according to IEEE802.11a/b/g/n/ac/d/h/e/i/r/w/v (2.4 GHz/5 GHz) is integrated into the HMI mobile
device. A BT-compatible short-range radio according to BT Standard V5.0 is also integrated.
8
WLAN security : WEP, WPA, IEEE802.11i (Personal and Enterprise), WPA2, AES, TKIP, WPA2-PSK,
802.1x: Authentication, 802.1x EAP, TLS, TTLS, PEAP, SIM, AKA, AKA-PRIME, PMK caching.
8
Standard encryptions are ACD-validated
®
