22.7 Connection cable
The connection cable has a length of 5 meters (a version with 10 meters is optionally available).
22.7.1 Technical Data of the cables
Outer Jacket
Number of Cores
Nominal Cross Section
Outer Ø
Minimum Bending Radius
Core Identification
Resistant to
Conditionally Resistant to
Features
Table 22: Technical data for connection cable
22.7.2 Pin Assignment
The control voltage for emergency stop and the enabling switch is 24 V DC.
The cable assignment is shown in the table below:
Core Color
Red
Blue
Purple
Green
Pink
Yellow
Brown
White
Black
Gray
Table 23: Pin assignment
Bedien-Projektierungshandbuch _M2Smart
Technical Data
PUR flame retardant, color black
10
0.34 mm²
7.5 mm
5x line Ø moved
3x line Ø not moved
To DIN 47100, by color
UV rays, oxygen, ozone, hydrolysis, oil
Microbes, hydraulic fluid, coolant emulsion, alkalis
Silicone and cadmium free
High abrasion resistance
Tear and cut resistant
Notch-resistant
Signal Name
+U
-U
SI_Enable_1_in
SI_Enable_1_Out
SI_Enable_2_In
SI_Enable_2_Out
SI_Stop_1_In
SI_Stop_1_Out
SI_Stop_2_In
SI_Stop_2_Out
®
HMI10 Wired_V1.10_de_en
Function
+ U charging voltage
- U charging voltage
Enabling switch Input 1
Enabling switch Output 1
Enabling switch Input 2
Enabling switch Output 2
Emergency Stop input 1
Emergency Stop output 1
Emergency Stop input 2
Emergency Stop output 2
