32 Accessories
The accessories of the M2Smart
32.1 Wall bracket for M2Smart
Passive wall bracket for secure mounting of the M2Smart
magnets for the M2Smart
screws are not included in the scope of delivery.
This wall bracket can optionally also be used with the cable holder.
Figure 37: Passive wall bracket for M2Smart
The holding magnets allow easy insertion and removal, as well as a secure hold of the M2Smart
Wired.
Material
Mounting
Dimensions
Weight
Table 27: Technical data for wall bracket
Bedien-Projektierungshandbuch _M2Smart
®
HMI10 Wired are described below:
®
HMI10 Wired
®
HMI10 Wired. Used for wall mounting of the bracket with 4x M6 screws. The
®
HMI10 Wired
Technical Data
Sheet steel, painted deep black (RAL 9005)
The bracket is mounted with 4x screws M6
Approx. 247 x 123 x 152 mm (L x W x H)
Approx. 1140 g
®
HMI10 Wired_V1.10_de_en
®
HMI10 Wired on the wall including holding
®
HMI10
